High Throughput Tissue Grinder

Model NO. BS-HTG Series

The BS-HTG Series High Throughput Tissue Grinder is a high-speed, multi-sample homogenization system designed for rapid disruption and grinding of biological samples.

Quantity

Features

High-speed vertical oscillation grinding technology
Simultaneous processing of multiple samples
Up to 192 samples per run
7-inch color touch screen interface
Programmable grinding parameters
Excellent repeatability and consistency
Fully enclosed grinding chamber
Cross-contamination prevention design
Noise level below 50 dB
Supports dry, wet, and frozen grinding
Optional low-temperature adapter available
Suitable for DNA, RNA, and protein extraction workflows

Advantages:

Utilizing vertical oscillation technology and grinding beads, the system efficiently processes tissue, plant, microbial, and environmental samples for DNA, RNA, protein, and metabolite extraction.

Specification：

Parameter	BS-HTG-24	BS-HTG-48	BS-HTG-96	BS-HTG-192
Sample Capacity	24/32×(0.2–0.5ml/1.5–2ml) 6/8×(7–15ml) 2×25ml 2×50ml	48×(0.2–0.5ml/2ml) 12×5ml 8×(7–15ml) 2×25ml 2×50ml	96×(0.2–0.5ml/2ml) 48×5ml 24×(7–15ml) 4×25ml 2×50ml	384×(0.2–0.5ml) 192×2ml 48×5ml 24×(7–15ml) 4×25ml 2×50ml
Display	7-inch Color Touch Screen
Sample Size	Adjustable According to Adapter
Final Particle Size	≤5 μm
Grinding Plates	1
Center Positioning/Fastening	Yes
Frequency	0–70 Hz
Grinding Time	0–9999 s
Acceleration/Deceleration Time	2 s
Grinding Ball Material	Stainless Steel / Zirconia
Grinding Ball Diameter	0.1–30 mm
Grinding Method	Dry / Wet / Frozen Grinding
Optional Function	Low Temperature Adapter
Dimensions	272 × 375 × 640 mm
Weight	25 kg
Power Supply	AC100–240V, 50/60Hz

Q: What samples can the BS-HTG Series process?
A: It is suitable for tissue, plant, microbial, and environmental samples.

Q: How many samples can be processed at once?
A: Depending on the model, up to 192 samples can be processed simultaneously.

Q: What grinding modes are available?
A: The system supports dry, wet, and frozen grinding.

Q: How does the system prevent cross-contamination?
A: Individual sample tubes and a fully enclosed chamber help minimize cross-contamination.

Q: Why choose BIOSTELLAR as your supplier?
A: BIOSTELLAR offers reliable quality, OEM/ODM services, competitive pricing, and professional global support.
