D500 Laboratory High Shear Homogenizer

• High-Shear Rotor–Stator Processing: Provides mechanical shearing action for dispersing and homogenizing compatible laboratory samples

• Six Selectable Speed Levels: Offers an operating range of 10,000–30,000 rpm for different processing requirements

• 550 W Motor: Delivers power for laboratory-scale mixing, dispersion and emulsification

• Versatile Sample Handling: Published processing capacity of 10–40,000 mL, depending on the dispersing configuration and sample properties

• 316L Stainless Steel and PTFE: Wetted dispersing components use materials suited to a range of laboratory sample preparations

• Removable Dispersing Assembly: Interchangeable rotor–stator components simplify cleaning and configuration changes

• Motor Protection: Overload protection and smooth-start operation support controlled startup and routine laboratory use

Applications

Food and Beverage Laboratories
Preparation of liquid food mixtures, emulsions and dispersed samples for formulation development and quality testing.

Pharmaceutical Research
Dispersion and blending of compatible liquid formulations during laboratory research and development.

Cosmetic Formulation
Preparation of creams, lotions and other emulsion-based experimental formulations.

Chemical Laboratories
Mixing of liquid systems and dispersion of suitable solid materials in liquid media.

Biotechnology Research
Mechanical homogenization of compatible research samples before subsequent laboratory analysis.

Certifications

• Made with high-quality 316L stainless steel for corrosion and autoclave resistance.
• Designed to meet international safety and quality standards for laboratory equipment.

Frequently Asked Questions (FAQ)

Q1. How does the D500 high shear homogenizer work?
The D500 uses a rotating rotor inside a stationary stator. The resulting mechanical shear helps disperse and homogenize the sample.

Q2. What is the speed range of the D500?
The operating range is 10,000–30,000 rpm, with six selectable speed levels.

Q3. What sample volumes can the D500 process?
The published capacity is 10–40,000 mL. The suitable volume for a specific application depends on the dispersing head configuration, sample viscosity and vessel conditions.

Q4. Can the D500 process viscous samples?
The published maximum viscosity is 10,000 mPa·s. Processing performance depends on the formulation, volume and operating conditions.

Q5. What materials come into contact with the sample?
The dispersing assembly uses 316L stainless steel and PTFE components.

Q6. Can the dispersing components be removed for cleaning?
Yes. The rotor–stator components are detachable, making them easier to access for cleaning and maintenance. Sterilization procedures should follow the instructions for the selected assembly.

Q7. Is the D500 an ultrasonic homogenizer?
No. The D500 is a mechanical high shear rotor–stator homogenizer. Ultrasonic homogenizers use acoustic energy and are a different equipment category.

Q8. What information should I provide to request a quotation?
Please specify your sample type, processing volume, approximate viscosity, required voltage and intended application so BIOSTELLAR can review the suitable configuration.
