BIOSTELLAR WJL-653/663/673 Factory Price Laser Granulometer Analyzer Shandong Laboratory Equipment Particle Size Measurement
CN¥140252.00 - 161289.80
WJL-653
1unit
Quantity
- brand name:BIOSTELLAR
- place of origin:Shandong, China
- capacity:/
- customized support:OEM, ODM
- material:/
- size:/
- warranty:1 Year
- Dispersion method:Wet/Dry
- Measuring Range:Wet 0.01-3000um /Dry 0.1-3000um
- Work Principle:Mie scattering theory
- Laser light source:Pure helium neon gas laser
- Repetitiveness deviation:<0.5%(national standard materials D50)
- Accuracy deviation:<0.5%(national standard materials D50)
- Levels of granularity:135
- Optional Accessory:Micro and corrosion-resistant injection dispersion system
- Operation System:Computer reverse control
- Interface:Ethernet/USB
Product Description
Product Details
* Measuring range reaches to 3000μm
* Large sample pool designed with Anti-particle aggregation and deposition
* Automatic operation includes auto-judgement of optical path deviation and sample window contamination
* Adjustable revolving speed, maximum to 5000 RPM
* Intelligent software provides data analysis: differential distribution, cumulative distribution, standard classification,
volume distribution, area distribution, quantity distribution, R-R distribution, custom classification, and item classification, with functions such as averaging, statistics, comparison, and pattern transformation
* Test report: there are particle size distribution curves, detailed particle size data tables and user-defined summary tables, and there are D3, D10, D50, D90, D97, D (1,0), D (3,2), D (4,3), span, peak particle size, specific surface area and other characteristic parameters, and there are multiple user-defined parameters that can be inputted as required; The weight specific surface area and volume specific surface area can be interchanged; It can save the granularity distribution graph and granularity data chart as pictures, and supports PDF, WORD and EXCEL report templates.
* Large sample pool designed with Anti-particle aggregation and deposition
* Automatic operation includes auto-judgement of optical path deviation and sample window contamination
* Adjustable revolving speed, maximum to 5000 RPM
* Intelligent software provides data analysis: differential distribution, cumulative distribution, standard classification,
volume distribution, area distribution, quantity distribution, R-R distribution, custom classification, and item classification, with functions such as averaging, statistics, comparison, and pattern transformation
* Test report: there are particle size distribution curves, detailed particle size data tables and user-defined summary tables, and there are D3, D10, D50, D90, D97, D (1,0), D (3,2), D (4,3), span, peak particle size, specific surface area and other characteristic parameters, and there are multiple user-defined parameters that can be inputted as required; The weight specific surface area and volume specific surface area can be interchanged; It can save the granularity distribution graph and granularity data chart as pictures, and supports PDF, WORD and EXCEL report templates.
Specification
Parameters/Mode | WJL-653 | WJL-663 | WJL-673 | ||
Dispersion method | Wet | Dry | Wet/Dry | ||
Measuring Range | 0.01-3000um | 0.1-3000um | Wet 0.01-3000um Dry 0.1-3000um | ||
Work Principle | Mie scattering theory | ||||
Measuring Method | Stirring and ultrasonic two- stage dispersion | Duckbill nozzle,oscillat- ing and Venturi two- stage dispersion | Wet mixing and ultrasonic two-stage dispersion Dry method -duckbill nozzle,oscillating and Venturi two-stage dispersion | ||
Laser light source | Pure helium neon gas laser | ||||
Optical path System | High transparency coated wide-angle lens,high-precision automatic centering (Equipped with light path deviation warning function) | ||||
Repetitiveness deviation | <0.5%(national standard materials D50) | ||||
Accuracy deviation | <0.5%(national standard materials D50) | ||||
Levels of granularity | 135 | ||||
Optional Accessory | Micro and corrosion-resistant injection dispersion system | ||||
Operation System | Computer reverse control | ||||
Interface | Ethernet/USB | ||||
Power supply | AC220V,50Hz,500W | ||||
Dimensions | Main system:1000×340×450mm Dry/Wet sampling system:350×210×350mm | ||||
Company Introduction
Prosperity Biotech (Shandong) Co., Ltd has always been a supplier of high-quality laboratory general-purpose small instruments and equipment in the industry. For many years, the company has used sophisticated technical solutions to improve product development and manufacturing. In the past two decades, hundreds of products have been developed and produced, covering six categories of pipetting products, distillation products, heating and stirring products, temperature control products, centrifuges and other small instruments. Used in different environments such as large, medium and small enterprises, scientific research institutions,etc. Among them, the BIOSTELLAR brand is well-known worldwide.
As a global production base, Prosperity Biotech also provides ODM/OEM for famous companies in the industry.
Certifications
Packing&Shipping
FAQ
1. who are we?
We are based in Shandong, China, start from 2018,sell to Africa(35.00%),Eastern Asia(20.00%),South America(15.00%),Eastern
Europe(15.00%),South Asia(5.00%),North America(5.00%),Mid East(5.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
OVEN,Incubator,Oxygen Generator,Spectrophotometer,Stirrer
4. why should you buy from us not from other suppliers?
In the past two decades, hundreds of products have been developed and produced, covering six categories of pipetting products,
distillation products, heating and stirring products, temperature control products, centrifuges and other small instruments.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW；
Accepted Payment Currency:USD,EUR;
Accepted Payment Type: T/T,L/C,Western Union;
Language Spoken:English,Chinese
We are based in Shandong, China, start from 2018,sell to Africa(35.00%),Eastern Asia(20.00%),South America(15.00%),Eastern
Europe(15.00%),South Asia(5.00%),North America(5.00%),Mid East(5.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
OVEN,Incubator,Oxygen Generator,Spectrophotometer,Stirrer
4. why should you buy from us not from other suppliers?
In the past two decades, hundreds of products have been developed and produced, covering six categories of pipetting products,
distillation products, heating and stirring products, temperature control products, centrifuges and other small instruments.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW；
Accepted Payment Currency:USD,EUR;
Accepted Payment Type: T/T,L/C,Western Union;
Language Spoken:English,Chinese
